Teac SL-D900 - CD PCB Assembly Details

18
REF. NO
PARTS NO. DESCRIPTION
CD PCB ASSY
REMARK
100-90MU1030
CD PCB
CD PCB ASSY
062-90MP3001
CN205
082-20400200
CONNECTOR 4PIN P=2MM
CN201
082-20600100
CONNECTOR 6PIN P=2.0MM
CN202
082-21150100
FPC CONNECTOR 11PIN P=1.25MM
CN204
082-20400100
CONNECTOR 4PIN P=2MM
CN200
082-21600305
FPC CONNECTOR 16PIN P=1MM
D200-207,210-213
077-00414801
DIODE IN4148
IC200
075-00922639
IC-SIJ9226
IC201
075-00925823
IC-KA9258D
IC202
075-35USBN39
IC-S3P825AXZZ
INDUCTOR 10UH
095-00100001
L200-203
076-00C94500
TR-2SC945
Q205,207,208
Q201,202
TR-2SA733
076-00A73300
076-00B54400
TR-2SB544F
Q203
CRYSTAL 12.0MHZ
093-11200000
XT203
CRYSTAL 16.9344MHZ
093-11693440
XT202
IC205 075-51FG0039
IC-TMC51F-G
IC203
075-00831039
IC-S5L8310W
IC204
075-51440039
IC-MSM51V4400E
Q204
076-C2001L00
TR-2SC2001L
ZD200
077-3005B20H
ZENER DIODE 3.6V
L204
095-00220001
INDUCTOR 22UH
L205
052-SRL50020
UPRIGHT FERRITE CORE
XT201
093-A0327682 CRYSTAL 32.768KHZ
CRYSTAL 8.0MHZ
093-08000000
XT200
CN203
082-23630300
FPC CONNECTOR 36PIN P=1.0MM
SL-D900
