Teac SL-D900 - Tuner PCB Assembly Details

REF. NO
PARTS NO. DESCRIPTION
TUNER PCB ASSY
REMARK
100-90MU1040
TUNER PCB
TUNER PCB ASSY
062-90MP3003
096-SLD90010
AM ANT COIL 66T:14T
056-10080001
FERRITER BAR D10x80MM
L402
AM FILTER L10.7MA5-A
081-31070201
CF402,CF403
FM FILTER SFU450B
081-04500000
CF404
D400,401
077-00414801
DIODE IN4148
CF400
054-0GP18000
FM ANT FILTER GFMB3
IC400
075-00182302
IC-LA1823
IC401
075-07213109
IC-SC72131
095-10220001
INDUCTOR 220UH
L406
079-D2930210
AM OSC COIL - RED
L403
079-SLD90410
AM IFT COIL - YELLOW
L404
DIODE ISV101
077-50010101
VD400,401
TRIMMER 20P
073-00020022
TC400,401
ZD400
ZENER DIODE 5.2V
CRYSTAL 4.5MHZ
093-04500000
XT400
077-3005B20H
TR-2SC1674L
076-C1674L00
Q400
Q401,402
076-00C94500
TR-2SC945
DIODE ISV149
077-50014901
VD402,403
L400,401
078-08500351
FM RF COIL 0.8X5X3.5T
095-00100001
INDUCTOR 10UH
L405
CF401
093-11070004
CER. FILTER JT10.7MG1-A
CN5
082-20600100
CONNECTOR 6PIN P=2MM
CN8
082-10240100
CONNECTOR 2PIN P=2.5MM
20
SL-D900
