Teac SL-D900 - Control PCB Assembly Details

REF. NO
PARTS NO. DESCRIPTION
CONTROL PCB ASSY
REMARK
100-90MU1020
CONTROL PCB ASSY
062-90MP3002
CONTROL PCB
LED01,02
094-03020301
LED 3MM-ORANGE
076-00C94500
TR-2SC945
Q300-303
080-90MP3021
LCD DISPLAY #TCM-4292
LCD1
SW01-05,07,09-012,
SW014,017,018
063-0GP28020
TACH SW H=5MM
SW06,08,015,016
063-D2800020
TACH SW SKHHALM
CN300
082-23630300
FPC CONNECTOR 36PIN P=1.0MM
22
SL-D900
SW013
063-SRL35090
TACH SW H=5.5MM
U01
083-00LT1000
RECEIVER SENSOR
