4
SL-D900
2-2-1 AM Tuner
ITEM
ADJUSTMENT POINT
ADJUSTMENT
SG SETTING
TUNER SETTING
AM
2. IFT
450kHz
1kHz, 30% mod
L404
3. ANT COIL
Repeat step 3
1404kHz
1kHz, 30% mod
1kHz, 30% mod
L402
TC401
AM ant coil
603kHz
1404kHz
603kHz
1. VOLTAGE
adjustment
1620kHz
L403
Check
VT
7.8-8.2V
522kHz
adjustment
4. TC401
adjustment
adjustment
repeat step 3
and 4
603kHz
Maximun output level
Maximun output level
Maximun output level
60 cm
AM Loop
AM Signal Generator
Antenna
PHONES
SL-D900
Fig. 2-2-2
1 k ohm
1 k ohm
AC Voltmeter
Digital multimeter
AM
S1
R407
R406
VT voltage
