Teac SR-L30DAB - Unit Controls Overview; Power and Standby Function; Tuning and Station Selection; Function and Mode Selection

6
Names of Each Control
The equipment draws nominal non-operating power from the AC
outlet with its POWER switch in the OFF position.
A FB C D E
H GJ I
POWER switch
Press this switch to turn the unit on or off (standby).
AUTO TUNING button
Press this button to activate auto location of all available DAB services.
Press once for UK services or, hold for longer than 2 seconds to activate
international search.
FUNCTION/FM MODE button
In DAB mode, activates features such as station order, manual tune, DRC
value, SW version indication, signal error rate. It is also possible to ‘tidy’
the station list to remove stations which are in the memory but have no
service provided.
In FM mode, pressing this button alternates between stereo mode and
mono mode.
C
B
A
