Teac X-10 - Page 25

ancnnaa»g§;n
anana»anawnina»nhnanagnanangnunuan
aana»a°a»n»nanana4an
REF. NO.
-12
- 13
- 14
- 15
- 16
-17
- 18
-19
- 20
-21
- 22
- 23
- 24
- 25
- 26
-27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
PARTS NO.
5163041000
5163042000
*6545022000
*§524071000
*5555668000
*5504732000
*5524218000
*5581066000
5800002600
*5555681 100
A 5152192000
A, 5152225000
4 5152226000
A 5152239000
5534714000
*5534685000
*5545024000
*5555664000
*5555671100
5163045000
*5168926100
*5167260000
*5143243000
*5122145000
*5122146000
*5134090000
*5122281000
*5122164000
*6553296000
*6552390000
*5552391000
*5122177000
*5122170000
*5122322000
*5122165000
*5122166000
*5122169000
*5122164000
*5122172000
*5122280000
*5122221000
*5168932401
*5555888000
DESCRIPTION
Solenoid, Pinch Roller
Solenoid, Pause
Pin, Solenoid
Spring, Solenoid
Plate, C
Plate Assy, Solenoid
Spring, Pinch Roller Pressure
Nut, Nylon; M4
Screw, Shoulder; F
Bracket, Power Transformer
Transformer, Power
Transformer, Power
Transformer, Power
Transformer, Power
Button, B
Rod, Switch
Shaft, Timer Solenoid
Plate, Joint
Bracket, Timer Switch
Solenoid, Timer
PCB Assy, TIMER
PCB, TIMER
Diode, ERB12-02G1 (D641)
Connector Plug, 2P (P641)
Connector Plug, 3P (P642)
Push Switch, 2-gang; DP4T ($32, $33)
Connector Socket, 3P (Red)
Connector Socket, 2P
Frame, Joint
Frame, PCB
Frame, HS
Connector Socket, 15P
Connector Socket, 8P
Connector Socket, 3P (Black)
Connector Socket, 3P
Connector Socket, 4P
Connector Socket, 7P
Connector Socket, 2P
Connector Socket, 11P
Connector Socket, 2P (Red)
Connector Socket, 2P (Black)
PCB Assy, CONTROL
Heat Sink, C
REMARKS
JAPAN
U.S.A., CANADA
GENERAL EXPORT
X-10R/X-10
Parts marked with *require longer delivery time than regular parts.
EUROPE, U.K., AUSTRALIA
Part of 5 -18
Part of 5 - 18
Part of 5 - 18
Part of 5 -18
Part of 5 - 18
25
