BATTERY CONNECTION
This ESC is designed for use with 2S (7.4V) to 4S (14.8V)
LiPo batteries. Use of other types of batteries is not
recommended and may cause damage to the ESC. Only
use batteries equipped with compatible connectors. Using
adapters may create extra electrical resistance and cause
damage to the ESC.
ESC POWER SWITCH
The ESC switch is equipped with two buttons. The bigger LED
backlit button is used to power ON or OFF the ESC and the
smaller button is used for calibration/setup.
ESC CALIBRATION
The ESC must be calibrated to your transmitter inputs. Reset
all settings inside the transmitter before the calibration.
A. Switch your transmitter ON.
B. Press and hold the setup button, then power ON the ESC.
Release the setup button as soon as the red LED on the
ESC starts to ash.
C. Calibrate the throttle points by pressing the setup button
once after each step.
1. Neutral point (1 ash)
2. Full throttle (2 ashes)
3. Full brakes/reverse (3 ashes)
D. The motor will run 3 seconds after the last step is
completed.
