- 75 -
EO3-11084
MA-1350-1 SERIES
PK-2 KEYBOARD
REMARKS: 1. The Nos. 1 through 130 marked on the PK-2 Keyboard are the KEY Nos. to be printed on
the left side of the program receipt issued in the operation on the preceding page. If each
KEY is not set with a PLU Code, the auto-preset PLU Code identical to the initial KEY No.
in the above figure will be active as its preset PLU Code
ex.) KEY No. 1 ... PLU Code 1
KEY No. 130 ... PLU Code 130
2. When a PLU code is assigned to a PLU Preset-code Key on the ECR Keyboard in the
operation on the preceding page, the Hardware Key Code which indicates the absolute
location of the key will be printed to the left of the assigned PLU Code. Since it is hard to
explain which location code corresponds to each key (due to an irregular numbering), it is
suggested to verify the positioning by simply depressing the KEY and reading the code in
the display (described in NOTE 1 on the preceding page). This reading operation is
applied to the PK-2 Keyboard as well.
11 21131516141 71 91 10181 111 121
12 22232526242 72 92 10282 112 122
13 23333536343 73 93 10383 113 123
14 24434546444 74 94 10484 114 124
15 25535556545 75 95 10585 115 125
16 26636566646 76 96 10686 116 126
17 27737576747 77 97 10787 117 127
18 288 38
6848 78 98 10888 118 128
19 29939596949 79 99 10989 119 129
20 3010 40 60 7050 80 100 11090 120 130
58
