TEC MA-1350-1 Series - Ribbon Cassette Installation

- 15 -
EO1-11126
MA-1350-1 SERIES
2
1
3
4
9. Installing the Ribbon Cassette
Turn the Control Lock to the OFF position.
To remove the Printer Cover, insert the Printer
Cover Key to the Printer Cover Lock, and turn it
90° clockwise.
Install the Ribbon Cassette as shown in the figure.
After installing the Ribbon Cassette, turn the knob
of the Ribbon Cassette in the direction of the ar-
row mark several times to remove the slack on
the ribbon.
Attach the Printer Cover.
OFF
Z
REG
X
SET
MGR
-
