23
9.2. SENSOR REMOVAL
This function is used to remove the sensors from a given zone.
9.3. INFORMATION
After this option has been selected, the display shows information about the actuator version, battery level, range and the
actuator opening level (%).
9.4. SETTINGS
ON – this function is used to enable the window sensor (it is possible only after the sensor has been registered).
Delay time – this function enables the user to set the delay time. When the delay time is over, the main controller
responds to window opening by disabling heating or cooling in a given zone.
Example: Delay time is set at 10 minutes. When the window is opened, the sensor sends a signal to the main
controller. From time to time the sensor sends information about current status of the window. If the window is still
open when the delay time is over (10 minutes), the main controller closes the actuators and disables the heating in
a given zone.
NOTE
If the delay time is set at 0, the controller will immediately send a signal to the actuators in order to close them.
VIII. FITTER'S MENU
Fitter’s menu is intended to be used by a qualified person in order to configure advanced controller settings.
1. CONTACT OPERATION MODEVOLTAGE-FREE CONTACT
The regulator will enable the voltage-free contact after the pre-defined delay time if any of the zones has not reached the
pre-set temperature (heating - if the temperature is too low; cooling - if the temperature is too high). The controller disables
the contact when the pre-set temperature has been reached.
Operation delay - the function allows the user to set the delay time of activating the additional contact after the
temperature drops below the pre-set value in any of the zones.
Remote operation - this function allows the user to enable a given contact from other controller which is registered
in EU-M-9 control panel.
Fitter
΄s menu
Operation delay
Voltage-free contact
Pump
Additional contacts Registration
Heating-cooling Operation mode
Valve 1 registration
Humidity protection
ON
Maksymalna wilgotność
Factory settings
