38
Example:
The controller handles central heating system with CH boiler and three valves. Gas boiler is connected to voltage-free
contact. The user selected standard regulator 1, standard regulator 2, TECH RS regulator and DHW
function. If any of these devicessignalizes the need for heating, the contact will close and the device will be active until a
ll the regulators reach their pre-set temperatures.
8.7. CIRCULATING PUMP
This function is used to control the pump which mixes hot water between the water tank and DHW receivers.
After activating this function the user sets the 24-hour cycle of pump pause and activation (with the accuracy of 30
minutes). In order to make setting the 24-hour cycle easier, the user may copy a selected time interval into the next one.
After the operation schedule is defined, the user sets the pump operation time and the pump pause time while the
previously selected time interval is active. The user may easily delete the previously saved settings in order to introduce
new intervals. Configuring operations schedule is described in detail in section 7.8.
