TheASCIIlistabouttheproductisshownasbelow.
ASCII Commands
Serial port protocol: Baud rate(default): 19200 Data bits: 8 Stop bits: 1 Check bit: 0
RS-232 Command Function description Feedback
s x av y! Switchxchannelinputtoychanneloutput AV x -> y
s x all! Switchxchannelinputtoallchanneloutput x to all
r all out!
Getthecorrespondingswitch state between
all output port and the input port
AV 1 -> 1, AV 2 -> 2...
r out 1!
Getthecorrespondingswitch state between
the x output port and the input port
AV x -> x
s ptp! onetoonebetweeninputandoutputchannels ptp
r link in x! Get the connection status of the x input port HDMIINx:connect
r link out x! Get the connection status of the x output port
HDMI OUTx:
disconnect
r link in all! Get the connection status of all input port
HDMIINx:connect/
disconnect
r link out all! Get the connection status of all input port
HDMIOUTx:connect/
disconnect
s x off! Turn off the x output channel out x off
s x on! Turn on the x output channel out x on
s all off! Turn off all the output channel all out off
s all on! Turn on all the output channel all out on
s edid x c y!
Copy the display EDID on the x output port to
the y input port
copy EDID from output
x to input y
s edid x d y!
Copy the built-in EDID number y to the x input
port
use default edid y to
input x
s edid all c y!
Copy the display EDID on the x output port
to all inputs
copy edid from output
y to all inputs
s edid all d y!
Copy the built-in EDID number y to all input
ports
use default edid y to
all input
s edid default!
Restore the default EDID (1080P 2) to each
input port
edid default
r edid x! Get the Edid state of the x input port
IN1:1080p,Stereo
Audio 2.0
r edid all! Query the EDID status of all ports
IN1:1080p,Stereo
Audio 2.0
