1000BASE-T1 MediaConverter EMC User Manual
14
3 CONFIGURATION OF THE DEVICE
The 1000BASE-T1 MediaConverter_EMC is configured by four DIP-Switches on the
front of the device.
DIP-Switch
Status
Description
1
ON (up)
OFF (down)
1000BASE-T1 Port is set to Master
1000BASE-T1 Port is set to Slave
2
ON (up)
OFF (down)
1000BASE-T1 Mode
100BASE-T1 Mode
3
ON (up)
OFF (down)
IEEE mode (A2)
Legacy Mode (A0)
4
ON (up)
OFF (down)
Frame Generator Enable
Frame Generator Disable
Table 3-1: Configuration of DIP-Switches
Note: In a 1000BASE-T1 Link one device must be set as Master, the other must be set
as Slave.
Note: In TestModes, press capital “T” in serial Terminal to select TestMode.
