Page9 / 27
TC4310 User’s guide
Wall Mounting
The number of the screw: 2 pcs.
Direction for wall mounting: Tuner downward or leftward or rightward.
Dimension for the screw: diameter: 3.5mm; length: 10mm.
There are 2 slots on the underside of the CABLE MODEM that can be used for wall mounting.
Note: When wall mounting the unit, ensure that it is within reach of the power outlet.
To do this:
Fig. 1-3 Wall Mounting
1. For THE CABLE MODEM, ensure that the wall you use is smooth, flat, dry and sturdy
and use the 2 screw holes.
2. The unit can be to use solid concrete wall and/ or hard wood wall.
