Technicolor TG582n User Manual

21
3 MANUAL INSTALLATION
DMS-CTC-20101206-0009 v1.0
3.3.2 Setting up a Wired Connection
Requirements
 Both your network device (for example, a computer, a gaming console,...) and Technicolor Gateway must have a free
Ethernet port.
 Your network device must be configured to obtain an IP address automatically. This is the default setting.
Ethernet cable
In your package, you will find a cable with yellow connectors. This is the Ethernet cable.
Procedure
Proceed as follows:
1 Connect one end of the Ethernet cable to one of the yellow Ethernet ports of your Technicolor Gateway:
2 Connect the other end of the Ethernet cable to your network device.
3 Your network device is now connected to your network. No additional configuration is needed unless specified by your
service provider.
The Technicolor Gateway does not support Power over Ethernet (PoE). All network devices that are connected
to the Technicolor Gateway must be powered by their own power source.

Technicolor TG582n Specifications

General

Type	ADSL Modem Router
Wi-Fi Standards	802.11b/g/n
Antenna	Internal
Security	WEP, WPA, WPA2
VoIP	No
Ethernet Ports	4
USB Ports	1 USB 2.0 port
ADSL Standards	ADSL2, ADSL2+
