12
1GETTING START
ED
DMS-CTC-20101206-0017 v1.0
Broadband LED (if you are using the DSL Gateway scenario)
Broadband LED (if you are using the Local Router scenario)
Internet LED
WPS LED
For more information about WPS, see “5.1 Connecting Your Wireless Client via WPS” on page 40.
Red Solid on No wireless activity, no security
Blinking Wireless activity, no security
Red/green Toggling Wireless client registration phase
Off Wireless access point disabled
Colour State Description
Green Solid on DSL line synchronised
Blinking Trying to detect carrier signal or pending DSL line synchronisation
Off Technicolor Gateway powered off.
Colour State Description
Green Solid on Connected to the WAN device
Off Not connected to the WAN device
Colour State Description
Green Solid on Connected to the Internet, no activity
Blinking Connected to the Internet, sending/receiving data
Red Solid on Failed to setup the Internet connection
Off No Internet connection
Colour State Description
Green Solid On Client successfully registered via WPS
Orange Blinking WPS registration ongoing
Red Blinking Error occurred
Colour State Description
