3 MANUAL INSTAL

LATION

DMS-CTC-20110713-0016 v2.0

Scenario 1: A MediaAccess Gateway with integrated filter

Proceed as follows:

1 Take the DSL cable. This is the gray cable that is included in your box.

2 Plug one end of the cable in the grey DSL port on the back of your MediaAccess Gateway.

3 Plug the other end of the cable:

 In the DSL/Modem output of your splitter/filter.

 Directly into the telephone wall outlet if there is no splitter/filter between the network terminator and your local

phone network.

Scenario 2: A MediaAccess Gateway without integrated filter

Proceed as follows:

1 Take the DSL cable. This is the grey cable that is included in your box.

2 Plug one end of the cable in the grey DSL port on the back of your MediaAccess Gateway.

3 Plug the other end of the cable into the DSL/MODEM output port of your filter/splitter.

DSL
