Technicolor tg799 User Manual

88
9NETWORK SERV
ICES
DMS-CTC-20110713-0016 v2.0
9.1.3 Configuring UPnP on the MediaAccess Gateway
Introduction
On the MediaAccess Gateway GUI you can:
 Enable/Disable UPnP.
 Enable/Disable Extended Security.
Enable/Disable UPnP
Proceed as follows:
1 Browse to the MediaAccess Gateway GUI.
For more information, see “Accessing the MediaAccess Gateway GUI” on page 37.
2 On the Toolbox menu, click Game & Application Sharing.
3 Under Universal Plug and Play:
 Select the Use UPnP check box, to enable UPnP.
 Clear the Use UPnP check box, to disable UPnP.
4 Click Apply.
Extended Security
If Extended Security is enabled, only limited UPnP operation between the host and the MediaAccess Gateway is allowed:
 A local host is not allowed to connect/disconnect the MediaAccess Gateway Internet connection. You can then only
connect/disconnect the Internet connection via the MediaAccess Gateway GUI
 Address translation mappings can only be added or changed via UPnP for the host on which the UPnP application is
running.
Extended Security is enabled by default.
Enable/Disable Extended Security
Proceed as follows:
1 Browse to the MediaAccess Gateway GUI.
For more information, see “Accessing the MediaAccess Gateway GUI” on page 37.
2 On the Toolbox menu, click Game & Application Sharing.
3 Under Universal Plug and Play, select Use Extended Security.
4 Click Apply.

Technicolor tg799 Specifications

General

Category	Gateway
VoIP	Yes
Wi-Fi Standards	802.11b/g/n
Ethernet Ports	4
Wireless Frequency	2.4 GHz
DSL Standards	VDSL2, ADSL2+
Security Features	WPA, WPA2, Firewall
DSL	VDSL2, ADSL2+
