36
TAPE_LED
O
Tape
Selector
LED
37 VCR_LED O VCR Selector LED
38 TV_LED O TV Selector LED
39 DVD_LED O DVD Selector LED
40 CD_LED O CD Selector LED
41 TUNER_LED O TUNER Selector LED
42 PHONO_LED O PHONO Selector LED
43 DIGITAL_LED O DIGITAL INPUT LED
44
DVD_6CH_LED
O DVD 6CH LED
45 LIMITTER O Power limitter control
output
46 TC916x_STB O Selector/Tuner (CK) clock
signal
47
TC916x_TNR_CK
O Selector/Tuner/DVD 6CH
SW-CK
48
TC916x_TNR_DT
O Selector/Tuner/DVD 6CH
SW-DT
49 S/C SP O Surround/Center speaker
control output
50 SP B O Speaker B control output
51 SP A O Speaker A control output
52 RELAY O Relay control output
53 AF_MUTE O Muting control output
54 SUBW_MUTE O Subwoofer muting
55 WAKE_LED - Wake up timer LED (Not
used, open)
56 VCR_MUTE O VCR RECORD MUTE
57~59
NOT USED - NOT USED
60~78
SEG19~ SEG1 O FL segment signal output
79~88
DEG1~ DEG10 O FL digit signal output
89 VEE - Power supply for FL driver
90
CS49326_SCDOUT
O CS49326 serial data
power output
91 CS49326_CDIN I CS49326 serial data
power input
92
CS49326_CCLK
I CS49326 serial clock
93 CS49326_CS I CS49326 chip selector
94
CS4226_RESET
I CS4226 reset
95
CS49326_RESET
I CS49326 reset
96 INIT_IN I Diode input intial settings
97 AVSS - Ground
98 VREF - Reference voltage
99 VIDEO_B O Video selector control
output B
100 VIDEO_A O Video selector control
output A
