Ref. No. Part No. Part Name & Description Pcs Remarks
P1 RPG5521 PACKING CASE / (SYSTEM) 1 (EP)
P2 RPQ0951 PAD(SYSTEM) 1
P3 RPG4397 PACKING CASE(RS) 1
P3 RPG4396 PACKING CASE(SA) 1
P3 RPG4398 PACKING CASE(SH) 1
P3 RPG4399 PACKING CASE(SL) 1
P4 RPN1195-2 PAD(RS) 1
P4 RPN1194 PAD(SA) 1
P4 RPN1196 PAD(SH) 1
P4 RPN1203 PAD(SL) 1
P5 RPF0139-1 PROTECTION BAG / (F.B.) 1
P6 SPP740-1 SHEET 4
PCB1 REP3115J-M MAIN P.C.B 1 [RTL]
PCB2 REP3116G-S SUB P.C.B 1 [RTL]
Q503 2SC5398RSTA TRANSISTOR 1 B1AACF000059
Q551 2SA1995RSTA TRANSISTOR 1 B1ACDF000006
Q554 2SA1995RSTA TRANSISTOR 1 B1ACDF000006
Q555 2SC3327A TRANSISTOR 1
Q601,02 2SC5398RSTA TRANSISTOR 2 B1AACF000059
Q607-10 2SC3327A TRANSISTOR 4
Q612 UN411FTA TRANSISTOR 1 UNR411F00A
Q671,72 2SD1859QRTV2 TRANSISTOR 2 B1BAAJ000003
Q673 2SB1417PQTA TRANSISTOR 1 2SB14170JA
Q701 2SD2374PQAU TRANSISTOR 1
2SD23740J1AU /
Q702 2SB1548PQAU TRANSISTOR 1
2SB15480J1AU /
Q705 2SA1995RSTA TRANSISTOR 1 B1ACDF000006
Q707 2SB1417PQTA TRANSISTOR 1
2SB14170JA /
Q708 UN4211 TRANSISTOR 1 UNR4211
Q709 2SC3327A TRANSISTOR 1
Q710 2SC3940AQSTA TRANSISTOR 1
2SC3940ARA /
Q711 2SB1548PQAU TRANSISTOR 1
2SB15480J1AU /
Q723 2SC3940AQSTA TRANSISTOR 1
2SC3940ARA /
Q725 2SC5398RSTA TRANSISTOR 1 B1AACF000059
Q726 2SC3940AQSTA TRANSISTOR 1
2SC3940ARA /
Q791 2SC3327A TRANSISTOR 1
Q901 UN4212TA TRANSISTOR 1 UNR421200A
Q902 UN411FTA TRANSISTOR 1 UNR411F00A
R151,52 ERDS2FJ102 1/4W 1K 2
R153,54 ERDS2FJ104 1/4W 100K 2
R155 ERDS2FJ121 1/4W 120 1
R157,58 ERDS2FJ102 1/4W 1K 2
R229,30 ERDS2FJ102 1/4W 1K 2
R509-12 ERDS2FJ470 1/4W 47 4
R544 ERDS2FJ103 1/4W 10K 1
R548 ERDS2FJ102 1/4W 1K 1
R551,52 ERDS2FJ683 1/4W 68K 2
R553,54 ERDS2FJ392 1/4W 3.9K 2
R555 ERDS2FJ152 1/4W 1.5K 1
R556 ERDS2FJ104 1/4W 100K 1
R557 ERDS2FJ103 1/4W 10K 1
22
