Technics SA-EH760

voltage is applied to speaker terminals.)
8. Type Illustration of ICs, Transistors and Diodes
9. Schematic Diagram Notes
- This schematic diagram may be modified at any time with the
development of new technology.
Notes:
S701:
Voltage selector switch (VOLT ADJ) / (GC) area only
S901:
Power Standby/on switch ( /I)
S902:
ECO mode switch (MODE)
S903:
Clock/timer, demo switch / (CLOCK/TIMER, DEMO)
S904:
Play timer/record timer switch / ( PLAY/ REC)
S905:
FM mode switch / (FM AUTO/MONO)
S906:
Tuning mode switch / (TUNING MODE)
S907:
Set switch (SET)
S908:
Source input switch / (INPUT SELECTOR)
S909:
6 ch discrete input switch / (6 CH DISCRETE INPUT)
14
