S910:
Tuning down switch (TUNING, )
S911:
Tuning up switch (TUNING, )
S912:
Tuner/band switch (TUNER/BAND)
S913:
Digital super woofer switch / (DIGITAL S.WOOFER)
S914:
KARAOKE switch (KARAOKE)
S915:
Echo switch (ECHO)
VR401:
Microphone volume control VR / (MIC VOL)
VR901:
Volume control VR (VOLUME)
- Indicated voltage values are the standard values for the unit
measured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard. Therefore, there may exist some
errors in the voltage values, depending on the internal impedance
of the DC circuit tester.
No mark
: Power ON (FM or AM)
- Important safety notice:
Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of components, be sure to use only
15
