Pin
No.
Terminal
Name
I/O Function
31
|
37
7G
|
1G
O
Grid signal output
38 NC - Not used, open
39
40
|
45
P1
|
P6
O
Segment signal output
46
V
DD
3
I Power supply terminal
47
|
50
P7
|
P10
O
Segment signal output
51 -VP I Power supply terminal (negative)
52
|
71
P11
|
P30
O
Segment signal output
72
V
DD
4
I Power supply terminal
73
|
77
P31
|
P35
O
Segment signal output
78 REGIN0 I Area select signal input
79 REGIN1
80
STANDBY
O LED (STANDBY) drive signal
output
81 TIMER O LED (TIMER) drive signal output
82 S.W LED O LED (DIGITAL S.WOOFER) drive
signal output
83 LOUNGE -
LED (LOUNGE) drive signal
output
(Not used, open)
84
CHORUS
-
LED (CHORUS) drive signal
output
(Not used, open)
85 MUTE O Muting signal output
86 POWER O Power control signal output
87 /ECO O ECO signal output
88 MUTE2 O Muting signal output
89
V
SS
2
- GND terminal
90
V
DD
2
I Power supply terminal
19
