Technics SA-EH760

Pin
No.
Terminal
Name
I/O Function
91 NC - Not used, open
92
93 RL4 - Not used, open
94 SH CS O Chip select signal output for
Sound Processor
95 SH DO O Serial communication signal to
Sound Processor (Data signal
output)
96 SH DI I Serial communication signal to
Sound Processor (Data signal
input)
97 SH CK I Serial communication signal to
Sound Processor (Clock signal
input)
98 E DET I Unusual condition detect signal
input
99 CR
TIMER
I/O TIME CONSTANT terminal
100
SD I Station detector signal input
from tuner circuit
14. Block Diagram
15. Replacement Parts List
Notes:
- Important safety notice:
Components identified by mark have special characteristics
important for safety.
Furthermore, special parts which have purposes of fire-retardant
(resistors), high-quality sound (capacitors), low-noise (resistors),
etc. are used.
When replacing any of components, be sure to use only
manufacture’s specified parts shown in the parts list.
- The <IA> <IB> <IC> marks in Remarks indicate language of
instruction manual.
<IA>: English, Chinese, Arabic
<IB>: English
<IC>: Spanish
- The parenthesized indications in the Remarks columns specify the
areas. (Refer to the cover page for area.)
