Technics SL-1210MK7

English
(08)
08
Numbers such as (

18) indicate reference pages.
Parts Name
Balance weight (

11)
Stylus pressure
control (

14)
Arm lock
(

16)
Arm-height
control ring
(

16)
Anti-skating
control
(

15)
Pitch range select
button (

20)

Arm clamp (

14)
Arm rest (

14)
Cue lever (

14)
Speed select buttons
(

18)


The LED lamps can be set to
blue or red with the LED colour
setting. (Factory setting Red)
(

17)
Turntable (

10)
Slipmat (

10)
Stylus light (

19)
EP record adaptor (

18)
Centre spindle (

10)
Insulator (

13)
START-STOP button (

18)
ON/OFF (power) (

18)
Strobe light (

20)

RESET button
(

19)
RESET LED lamp
(

19)

PITCH ADJ control
(

20)
Head shell (

9)
Locking nut (

9)
Tone arm (

9,11)
Head shell stand (

9)
Back
Front
PHONO output terminal (

12)
AC (
) input terminal (

12)
PHONO earth terminal (

12)
PHONO
EARTH
PHONO OUT
L
R
