Technics SL-1500C

TechnicalInformation forHi‐Fi Audio System
ON/OFF button
START/STOP
button
Tone  arm
Turntable
Centerspindle
Balanceweight
Anti‐skatingcontrol
Cuelever
Headshellwithcartridge
*Theheadshellcomeswith
acartridgeequivalentto
“ortofon 2MRed”.
Turntablemat
リフトアップ
スイッチ
Backside
Arm‐height
adjuster
Speedselectbuttons
 33
 45
 78（Press[33]and[45]
buttonsatthesametime）
Autolift‐up
switch
External
output
terminal
External
output
switch
PHONO
output
terminal
PHONOearth
terminal
Parts name
52mm
Whenplayingarecord,
removethestyluscover.
Whenplayingarecord,
removethestyluscover.
Adjusttheoverhangin
thatthestylustipisat
52mm fromtheheadshell
mountingend.
Adjusttheoverhangin
thatthestylustipisat
52mm fromtheheadshell
mountingend.
Whenreplacingstylus,
removeitasfollows.
Whenreplacingstylus,
removeitasfollows.
