Technics SL-1500C

TechnicalInformation forHi‐Fi Audio System
Removetheturntablesheet,
turntableandheadshell.
Turntheunitupsidedown,placeit
onathickpadordustcoverand
removescrews.
Fixtonearmwith
thearmclamp
Need
unsoldering
(5cables)
Releasethearmlockandthen
pullitup.
Remove2screws
Noneedto
remove
PhonoEqualizercircuit
Service information – Disassembly * Refer to service manual for more details
Putacushionsuchaswhat
isusedforpackingproducts,
tofixthetonearm
completely.
Releasethearm
lock.
15
