Technics SL-1500C

TechnicalInformation forHi‐Fi Audio System
①Releasethearmclamper
②Lowerthecueleverslowlyonce
③Raisethecueleverandmove
thetonearmovertherecord
④Lowerthecueleverslowlytoletthemusicstart
⑤Thetonearmautomaticallyliftsupafter
arecordfinishesplaying(Thismaytakeup
toapprox.90seconds)
■Thisfunctionautomaticallyliftsupthetonearmaftera
recordfinishesplaying.Itpreventsthelastgroovefromplaying
backrepeatedly.
*1Itdoesnotstoptheturntablerotation
*2Thetonearmjustliftsupanditdoesn’treturntothe
originalposition.
■Theopticalsensorfordetectingthetonearmposition,aspring
forliftingthetonearmandtheelectromagneticcoilare
equippedinsidethetonearmunit.
Byloweringthecuelever,theelectromagneticcoilandspring
movetotheinitialposition.
Whenthetonearmmovestoneartheinnermost
circumference,theopticalsensordetectsit.Aftertheelapseof
acertainperiodoftime, itactivatestheelectromagneticcoiland
liftsthetonearmup.
Electromagnetic
coil
Opticalsensor
Spring
*Sincethesepartsrequirehighmanufacturingaccuracy,they
cannotbereplacedindividually.Pleasereplacethetonearmunit.
Service information – Auto Lifter Function
16
