Technics SL-DZ1200PP - Page 57

264
ARM_A20
-
Not
used.
(
Open)
Pin
No.
Terminal
Name
I/O Function
265 ARM_A19 O External address bus
(address bus signal for
external bus)
266 ARM_A18 O External address bus
(address bus signal for
external bus)
267 ARM_A17 O External address bus
(address bus signal for
external bus)
268 ARM_A16 O External address bus
(address bus signal for
external bus)
269 ARM_A15 O External address bus
(address bus signal for
external bus)
270 ARM_A14 O External address bus
(address bus signal for
external bus)
271 ARM_A13 O External address bus
(address bus signal for
external bus)
272 ARM_A12 O External address bus
(address bus signal for
external bus)
273 ARM_A11 O External address bus
(address bus signal for
external bus)
274 ARM_A10 O External address bus
(address bus signal for
external bus)
275 CV
DD
8 P Power supply
276 CGND8 P DE
277 ARM_A9 O External address bus
(address bus signal for
external bus)
278 ARM_A8 O External address bus
(address bus signal for
external bus)
279 ARM_A7 O External address bus
(address bus signal for
external bus)
280 ARM_A6 O External address bus
(address bus signal for
external bus)
