Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
281 ARM_A5 O External address bus
(address bus signal for
external bus)
282 ARM_A4 O External address bus
(address bus signal for
external bus)
283 ARM_A3 O External address bus
(address bus signal for
external bus)
284 ARM_A2 O External address bus
(address bus signal for
external bus)
285 ARM_A1 O External address bus
(address bus signal for
external bus)
286 ARM_A0 O External address bus
(address bus signal for
external bus)
287 EUM0 I/O Not used. (’H’)
288 EUM1 I/O Not used. (’H’)
17.3. IC34(C0ZBZ0000910): / MULTIMEDIA DIGITAL IMAGE
PROCESSOR / (MD Microcomputer)
Pin
No.
Terminal
Name
I/O Function
1 DSP_BDX0 - Not used. (Open)
2
DSP_BCLKX0
I/O Not used. (’H’)
3
DSP_BFSX0
I/O Not used. (’H’)
4 DSP_BDR0 I Not used. (’H’)
5
DSP_BCLKR0
I/O Not used. (’H’)
6
DSP_BFSR0
I/O Not used. (’H’)
7 DV
DD
1 P Power supply
8
DSP_CLKS0
I Not used. (’H’)
9 DGND1 P DE
10 RXD0 I SC DSC25 receiving data
11 TXD0 O SC DSC25 transmitting
data
12 RXD1 I Not used. (’H’)
13 TXD1 - Not used. (’Open’)
14 SCLK0 - Not used. (’L’)
15 SDI0 - Not used. (’L’)
