Pin
No.
Terminal
Name
I/O Function
1 PD I APC Amp. input terminal
2 LD O APC Amp. output terminal
3 V
CC
1 I Power supply terminal 1
4 TFLT I TE Amp. analog SW &
VREF2 Buffer control
terminal
5 LDON I APC & STANDBY control
terminal
6 RFOUT - Not used, open
7 EQCTL I EQ characteristic control
terminal
8 RFC I The capacity connection
terminal for the AGC
input HPF
9 CAGC I AGC loop filter
connection terminal
10 ARF O AGC output terminal
11 CEA I The capacity connection
terminal for HPF-Amp.
12 3TOUT O 3 TENV Output Terminal
13 CBDO I The capacity connection
terminal for RF - side
envelope detection
14 BDO O BDO output terminal
15 COFTR I The capacity connection
terminal for RF + side
envelope detection
16 OFTR O OFTR output terminal
17 NRFDET O NRFDET output terminal
18 GND - GND
19 TVREF2 O VREF2 Buffer output
terminal
20 VREF1 O VREF1 output terminal
21 V
CC
2 I Power supply terminal 2
22 VREF2 O VREF2 output terminal
23 TEN O TE Amp. reversal input
terminal
24 TEOUT O TE Amp. output terminal
25 FTEO - Not used, open.
26 FEN I FE Amp. reversal input
terminal
27 FEOUT O FE Amp. output terminal
28
GCTRL
I
GCTL
terminal
68
