Technics SL-DZ1200PP User Manual

Pin
No.
Terminal
Name
I/O Function
276 CGND8 P DE
277 ARM_A9 O External address bus
(address bus signal for
external bus)
278 ARM_A8 O External address bus
(address bus signal for
external bus)
279 ARM_A7 O External address bus
(address bus signal for
external bus)
280 ARM_A6 O External address bus
(address bus signal for
external bus)
281 ARM_A5 O External address bus
(address bus signal for
external bus)
282 ARM_A4 O External address bus
(address bus signal for
external bus)
283 ARM_A3 O External address bus
(address bus signal for
external bus)
284 ARM_A2 O External address bus
(address bus signal for
external bus)
285 ARM_A1 O External address bus
(address bus signal for
external bus)
286 ARM_A0 O External address bus
(address bus signal for
external bus)
287 EUM0 I/O Not used. (’H’)
288 EUM1 I/O Not used. (’H’)
17.4. IC1(AN8882SB-E1): / SERVO AMP.
67
