Pin
No.
Terminal
Name
I/O Function
257 ARM_D4 I/O External data bus (data
bus signal for external bus)
258 ARM_D3 I/O External data bus (data
bus signal for external bus)
259 ARM_D2 I/O External data bus (data
bus signal for external bus)
260 ARM_D1 I/O External data bus (data
bus signal for external bus)
261 ARM_D0 I/O External data bus (data
bus signal for external bus)
262 ARM_A22 - Not used. (Open)
263 ARM_A21 - Not used. (Open)
264 ARM_A20 - Not used. (Open)
265 ARM_A19 O External address bus
(address bus signal for
external bus)
266 ARM_A18 O External address bus
(address bus signal for
external bus)
267 ARM_A17 O External address bus
(address bus signal for
external bus)
268 ARM_A16 O External address bus
(address bus signal for
external bus)
269 ARM_A15 O External address bus
(address bus signal for
external bus)
270 ARM_A14 O External address bus
(address bus signal for
external bus)
271 ARM_A13 O External address bus
(address bus signal for
external bus)
272 ARM_A12 O External address bus
(address bus signal for
external bus)
273 ARM_A11 O External address bus
(address bus signal for
external bus)
274 ARM_A10 O External address bus
(address bus signal for
external bus)
275 CV
DD
8 P Power supply
66
