Technics SL-DZ1200PP User Manual

Pin
No.
Terminal
Name
I/O Function
234 MXO O 27MHz clock output (core
clock 27MHz oscillator
output)
235 CGND7 P DE
236 CE0 O SD I/F chip selection (CE
signal for SD I/F (MN5772))
237 CE1 O CD chip selection (CE
signal for CD)
238 EM_WE O Write enable (WE signal
for external bus)
239 EM_OE O Read enable (OE signal for
external bus)
240 EM_RDWR - Not used. (Open)
241 SCE - Not used. (Open)
242 FLSH_CE O ROM#0 chip selection (CE
signal for 16M FLASH/
MASK ROM)
243 BUSWIDTH I External bus width setup
('H' 16bit)
244 ARM_D15 I/O External data bus (data
bus signal for external bus)
245 ARM_D14 I/O External data bus (data
bus signal for external bus)
246 ARM_D13 I/O External data bus (data
bus signal for external bus)
247 ARM_D12 I/O External data bus (data
bus signal for external bus)
248 ARM_D11 I/O External data bus (data
bus signal for external bus)
249 ARM_D10 I/O External data bus (data
bus signal for external bus)
250 ARM_D9 I/O External data bus (data
bus signal for external bus)
251 ARM_D8 I/O External data bus (data
bus signal for external bus)
252 ARM_D7 I/O External data bus (data
bus signal for external bus)
253 ARM_D6 I/O External data bus (data
bus signal for external bus)
254 DV
DD
8 P Power supply
255 DGND8 P DE
256 ARM_D5 I/O External data bus (data
bus signal for external bus)
65
