Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
197 SDR_DQ4 I/O SDRAM data bus
198 SDR_DQ3 I/O SDRAM data bus
199 DVDD9 P Power supply
200 SDR_DQ2 I/O SDRAM data bus
201 SDR_DQ1 I/0 SDRAM data bus
202 SDR_DQ0 I/O SDRAM data bus
203 CV
DD
6 P Power supply
204 CGND6 P DE
205 CFQE - Not used. (Open)
206 CFE1 - Not used. (Open)
207 CFE2 - Not used. (Open)
208 CFRST - Not used. (Open)
209 STSCHG - Not used. (Open)
210 CFWAIT - Not used. (Open)
211 CFD1 - Not used. (Open)
212 CFD2 - Not used. (Open)
213 CFRDY - Not used. (Open)
214 IOIS16 - Not used. (Open)
215 CFIORD - Not used. (Open)
216 CDIOWR - Not used. (Open)
217 SD_DATA1 I Not used. (Open)
218 SD_DATA0 I Not used. (Open)
219 SD CLK - Not used. (Open)
220 SD_CMD I Not used. (Open)
221 SD_DATA3 I Not used. (Open)
222 SD_DATA2 I Not used. (Open)
223 DV
DD
7 P Power supply
224 DGND7 P DE
225
EM_BUSACK
- Not used. (Open)
226
EM_BUSREQ
I Not used. (’H’)
227 EM_WAIT I CD ROM WAIT
228 EM_BEL - Not used. (Open)
229 EM_BEM - Not used. (Open)
230 PLLGND3 P DE
231 PLLV
DD
3 P Power supply
232 CV
DD
7 P Power supply
233 MXI I 27MHz clock input (core
clock 27MHz oscillator
input)
64
