Technics SL-DZ1200PP

155
SDR_A8
O
SDRAM
address
bus
Pin
No.
Terminal
Name
I/O Function
156 SDR_A7 O SDRAM address bus
157 SDR_A6 O SDRAM address bus
158 SDR_A5 O SDRAM address bus
159 DV
DD
5 P Power supply
160 SDR_A4 O SDRAM address bus
161 SDR_A3 O SDRAM address bus
162 SDR_A2 O SDRAM address bus
163 SDR_A1 O SDRAM address bus
164 SDR_A0 O SDRAM address bus
165 DGND5 P DE
166 SDR_DQ31 I/O SDRAM data bus
167 SDR_DQ30 I/O SDRAM data bus
168 SDR_DQ29 I/O SDRAM data bus
169 SDR_DQ28 I/O SDRAM data bus
170 SDR_DQ27 I/O SDRAM data bus
171 SDR_DQ26 I/O SDRAM data bus
172 SDR_DQ25 I/O SDRAM data bus
173 CV
DD
5 P Power supply
174 CGND5 P DE
175 SDR_DQ24 I/O SDRAM data bus
176 SDR_DQ23 I/O SDRAM data bus
177 SDR_DQ22 I/O SDRAM data bus
178 SDR_DQ21 I/O SDRAM data bus
179 SDR_DQ20 I/O SDRAM data bus
180 SDR_DQ19 I/O SDRAM data bus
181 SDR_DQ18 I/O SDRAM data bus
182 SDR_DQ17 I/O SDRAM data bus
183 SDR_DQ16 I/O SDRAM data bus
184 SDR_DQ15 I/O SDRAM data bus
185 SDR_DQ14 I/O SDRAM data bus
186 SDR_DQ13 I/O SDRAM data bus
187 SDR_DQ12 I/O SDRAM data bus
188 SDR_DQ11 I/O SDRAM data bus
189 DV
DD
6 P Power supply
190 DGND6 P DE
191 SDR_DQ10 I/O SDRAM data bus
192 SDR_DQ9 I/O SDRAM data bus
193 SDR_DQ8 I/O SDRAM data bus
194 SDR_DQ7 I/O SDRAM data bus
195 SDR_DQ6 I/O SDRAM data bus
196 SDR_DQ5 I/O SDRAM data bus
