Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
115 C_DATA10 I Not used. (’L’)
116 C_DATA11 I Not used. (’L’)
117 CV
DD
4 P Power supply
118 C_PCLK I Not used. (’L’)
119 CGND4 P DE
120 C_VSYNC - Not used. (’H’)
121 C_HSYNC - Not used. (’H’)
122 C_FIELD - Not used. (’H’)
123 LCD_SCLK - Not used. (Open)
124 LCD_DO7 - Not used. (Open)
125 LCD_DO6 - Not used. (Open)
126 LCD_DO5 - Not used. (Open)
127 LCD_DO4 - Not used. (Open)
128 LCD_DO3 - Not used. (Open)
129 LCD_DO2 - Not used. (Open)
130 LCD_DO1 - Not used. (Open)
131 LCD_DO0 - Not used. (Open)
132 PLLV
DD
2 P Power supply
133 PLLGND2 P DE
134 LCD_OE - Not used. (Open)
135 BLIGHT - Not used. (Open)
136 DV
DD
4 P Power supply
137 EXTCLK I Not used. (PULL UP(100K))
138 DGND4 P DE
139 SDR_CS O SDRAM chip selection
140 SDR_CLK O SDRAM clock
141 SDR_RAS O SDRAM RAS
142 SDR_CAS O SDRAM CAS
143 SDR_WE O SDRAM Write Enable
144 SDR_CKE O SDRAM Clock Enable
145
SDR_DQMHH
O SDRAM DQ signal
146
SDR_DQMHL
O SDRAM DQ signal
147
SDR_DQMLH
O SDRAM DQ signal
148
SDR_DQMLL
O SDRAM DQ signal
149 SDR_A14 O SDRAM address bus
150 SDR_A13 O SDRAM address bus
151 SDR_A12 - Not used.
152 SDR_A11 - Not used.
153 SDR_A10 O SDRAM address bus
154 SDR_A9 O SDRAM address bus
155 SDR_A8 O SDRAM address bus
