Technics SL-DZ1200PP

Pin
No.
Terminal
Name
I/O Function
77 PLLGND1 P DE
78 DV
DD
3 P Power supply
79 M40XI I Not used. (’H’)
80 M40XO - Not used. (’H’)
81 DGND3 P DE
82 HSYNC - Not used. (’Open’)
83 VSYNC - Not used. (’Open’)
84 CV
DD
3 P Power supply
85 C_WEN I Not used. (’L’)
86 C_DATA0 I Not used. (’L’)
87 C_DATA1 I Not used. (’L’)
88 C_DATA2 I Not used. (’L’)
89
C_DATA3
I Not used. (’L’)
90 CGND3 P DE
91 IREF_B - Not used.
92 DAOUT_B - Not used. (’Open’)
93 V
SS
A1 P AE
94 V
DD
A1 P Power supply
95 BIAS_B I VIDEO bias voltage (it is
GND connection at 0.1 F)
96 VREF_RGB I Not used.
97 IREF_G - Not used.
98 DAOUT_G - Not used. (’Open’)
99 V
SS
A2 P AE
100 V
DD
A2 P Power supply
101 BIAS_G I VIDEO bias voltage (it is
GND connection at 0.1 F)
102 V
SS
3V P Power supply
103 V
DD
3V P Power supply
104 IREF_R - Not used.
105 DAOUT_R - Not used. (Open)
106 V
SS
A3 AE
107 V
DD
A3 P Power supply
108 BIAS_R I VIDEO bias voltage (it is
GND connection at 0.1 F)
109 C_DATA4 I Not used. (’L’)
110 C_DATA5 I Not used. (’L’)
111 C_DATA6 I Not used. (’L’)
112 C_DATA7 I Not used. (’L’)
113 C_DATA8 I Not used. (’L’)
114 C_DATA9 I Not used. (’L’)
61
