TE IC702-
33 pin
1.7 V
FOD IC702-
28 pin
1.7 V 1.7 V
TRD IC702-
27 pin
1.7 V 1.7 V
/RFDET IC702-
38 pin
0 V 3.3 V
RF TJ701
1.0 V
STAT IC702-
17 pin
3.3 V 0 V
E04, E06,
E0C, E0E,
Best Eye
(PD
balance)
adjustment
not
completed
in the
specified
time
period.
Scratches or
contaminants
on disc
surface.
Focus and
Tracking
servo circuit
(check
waveforms,
voltages and
part values.)
Optical
pickup.
FBAL IC702-
30 pin
1.7 V 1.7 V
RF IC701-8
pin
1.0 V
FE IC702-
32 pin
1.7 V
OFT IC702-
36 pin
0 V 0 V
file:///C|/Documents%20and%20Settings/Administrator/Plocha/SL-EH570/s0603000000.htm (2 of 3) [25.4.2003 20:57:01]
