2.1 Handling of traverse deck (optical
pickup)
TOP PREVIOUS NEXT
1. Do not subject the traverse deck (optical pickup) to static electricity as it is extremely sensitive to
electrical shock.
2. To protect the laser diode against electrostatic breakdown, short the flexible board (FFC board)
with a clip or similar object. Refer to
Fig. 2-1.
3. Take care not to apply excessive stress to the flexible board (FFC board).
4. Do not turn the variable resistor (laser power adjustment). It has already been adjusted. Refer to
Fig. 2-1.
Fig. 2-1.
