● S614:
Play switch (
)
● S615:
Stop switch (
)
● S616:
R.Skip/search switch (
)
● S701:
Rest detect switch in OFF position
● S790:
Tray open detect switch in OFF position
● S791:
Tray close detect switch in OFF position
● Indicated voltage values are the standard values for the unit measured by the DC electronic circuit
tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors
in the voltage values, depending on theinternal impedance of the DC circuit tester.
❍ No mark
: CD Stop
❍ ( )
