29 MLD O Command load output
30 STAT I Status signal input
31 HALH - CD mechanism motor speed control signal output (Not used, open)
32 PL - Not used, open
33 CW O CD mechanism motor control signal output (forward direction)
34 CCW O CD mechanism motor control signal output (reverse direction)
35 PSTN - Not used, open
36 SW1 - Not used, open
37 SW2 - Not used, open
38 SW3 I Disc tray open detect signal input
39 SW5 - Not used, open
40 KEY2 I Operation key signal input
41 KEY1 I Operation key signal input
42 SW4 I Disc tray close detect switch signal input
•@
