56 SBCK - Sub-code serial input data
(Not used, connected to GND)
57 VSS - GND terminal
58 X1 IN I Crystal oscillator terminal (f=16.9344 MHz)
59 X2 OUT O
60 VDD I Power supply terminal
61 BYTCK - Byte clock signal (Not used, open)
62 /CLDCK - Sub-code frame clock signal
(Not used, open)
63 FCLK O Crystal frame clock
64 IPFLAG - Interpolation flag terminal (Not used, open)
65 FLAG - Flag terminal (Not used, open)
66 CLVS - Turntable servo phase synchro signal
(Not used, open)
67 CRC - Sub-code CRC check terminal
(Not used, open)
68 DEMPH - De-emphasis ON signal (Not used, open)
69 RESY - Re-synchronizing signal of frame sync.
(Not used, open)
70 IOSEL I I/O select signal input (Connected to VDD)
71 /TEST I Test terminal
(Not used, connected to power supply)
72 AVDD1 I Power supply terminal
73 OUTL O L ch audio signal output
74 AVSS1 - GND terminal
75 OUTR O R ch audio signal output
76 RSEL I Polarity direction control terminal of RF signal (Not used, connected to power supply)
77 IOVDD I Power supply terminal
78 PSEL - Test terminal (Connected to GND)
79 MSEL - Output frequency select signal input
(Not used, connected to GND)
80 SSEL I SUBQ output mode select signal input
(Not used, connected to VDD)
•@
