10
≥ If radio reception is poor, use a DAB outdoor antenna (not supplied).
≥ Do not use any other indoor antennas except the supplied DAB indoor antenna.
Connect only after all other connections are completed.
≥ This unit consumes a small amount of AC power (> 33) even the power switch lever is in the [OFF] position. Remove the plug from the main
electrical outlet if you will not be using the unit for an extended period of time. Place the unit so the plug can be easily removed.
Antenna connection
AC mains lead connection
This unit
(rear)
Adhesive tape
(not supplied)
DAB indoor antenna
(supplied)
Be sure to tighten the nut fully.
Place the antenna where reception is best.
AC mains lead
(supplied)
To a household mains socket
This unit
(rear)
Insert the AC mains lead up
to A, a point just before the
round hole.
(10)
ST-C700DE-TQBM0007.book 10 ページ ２０１６年１０月２６日 水曜日 午後１時１７分
