Technics ST-HD501

Pin
No.
Mark I/O /
Division
Function
62 KOUT2 I Key control adaptor input
terminal / (Not used,
connected to GND)
63 KIN2 O Key control adaptor output
terminal (Not used, open)
64 BPOUT O Band pass filter amp output
terminal for vocal cancel
65 BPIN I Band pass filter amp input
terminal for vocal cancel
66 CD I Input terminal for Rch
67 TUNER
68 MD
69 TAPE
70 AUXH
71 AUXL
72 AVSS O Power supply terminal
73 AGND — GND terminal
74 AUXL I Input terminal for Lch
75 AUXH
76 TAPE
77 MD
78 TAPE
79 CD
80 DELIN I R/L input terminal for
surround
- IC701 (M30218MAA103): FL DRIVE/ SYSTEM CONTROL
