Parts without these indications can be used for all areas.
*Capacity values are in microfarads (uF) unless specified otherwise, P=Pico-farads (pF) F=Farads
(F)
*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000k (OHM)
Ref. No.
Part No. Part Name & Description Pcs Remarks
1 RHD30073-K SCREW 4
2 RKM0398-S CABINET 1
3 XTB3+8JFZ SCREW 1
4 REZ1120 FLAT CABLE(14P) 2
5 RKA0076-N2 FOOT 4
5-1 RKA0083-K CUSHION 4
6 XTB3+6G SCREW 4
7 RMN0195 FL HOLD PIECE 2
8 RGK1138-N SIDE ORNAMENT(L) 1
9 RGK1139-N SIDE ORNAMENT(R) 1
10 RGU1394B-S BUTTON 1
11 XTBS26+8J SCREW 9
12 XTBS3+8JFZ1 SCREW 9
13 XTB3+12JFZ SCREW 4
14 RFKGTHD501EN FRONT PANEL ASS’Y 1
15 RGK0817-1M SIDE PANEL (L) 1
16 RGK0818-1M SIDE PANEL (R) 1
C101 ECBT1C103NS5 16V 0.01U 1
C102 ECEA1CKS101 16V 100U 1
C103 ECBT1C103NS5 16V 0.01U 1
C104,05 ECBT1H102KB5 50V 1000P 2
C106 ECBT1C103NS5 16V 0.01U 1
C107 ECBT1H473ZF5 50V 0.047U 1
C108 ECBT1H8R2KC5 50V 8.2P 1
C109 ECBT1H102KB5 50V 1000P 1
C110 ECBT1C103NS5 16V 0.01U 1
C111 ECEA1EKS4R7 25V 4.7U 1
C112 ECBT1C103NS5 16V 0.01U 1
C113 ECBT1H102KB5 50V 1000P 1
C114 RCE1HKA3R3BG 50V 3.3U 1
C115 ECEA1EKS4R7 25V 4.7U 1
C116 ECFR1C333KR 16V 0.033U 1
C117,18 ECFR1C183KR 16V 0.018U 2
C119 ECQP1391JZ 100V 390P 1
C120 RCE1CKA100BG 16V 10U 1
C121 RCE1HKAR47BG 50V 0.47U 1
C122,23 ECEA1HKS010 50V 1U 2
C124 ECBT1H101KB5 50V 100P 1
C125 ECEA1CKS220 16V 22U 1
C126 ECBT1H473ZF5 50V 0.047U 1
C127 ECEA1CKS220 16V 22U 1
C129,30 ECEA0JKS101 6.3V 100U 2
C131 ECBT1H101KB5 50V 100P 1
C132 ECBT1H102KB5 50V 1000P 1
C133,34 ECBT1H270JU5 50V 27P 2
C136 ECBT1H102KB5 50V 1000P 1
16
