Technics ST-HD501

Ref. No.
Part No. Part Name & Description Pcs Remarks
D711 MA111TX DIODE 1
D713,14 MA111TX DIODE 2
FL701 RSL0273-F FL 1
IC101 LA1833MN-TLM IC 1
IC102 LC72131MDTLM IC 1
IC301 M5218AFPE3 IC 1
IC302 M62433AFP IC 1
IC501 LC72722PMTLM IC 1
IC701 M30218MAA103 IC 1
JK101 RJH5210M JACK ANTENNA 1
JK201 SJF3069-20N EXT/MD 1
JK401 RJT065K20 SYSTEM CONNECTOR(20P) 1
JK402 RJT065K19 SYSTEM CONNECTOR(19P) 1
L101,02 ELESNR68MA COIL 2
L103 ELEXTR47MA9 COIL 1
L501,02 RLQA100JT-Y COIL 2
L541,42 RLQA100JT-Y COIL 2
L701 RLBN300AV-W COIL 1
L702-04 RLBN601V-W COIL 3
L706 RLBN601V-W COIL 1
L707 RLBN300AV-W COIL 1
Q101,02 2SC2787FK TRANSISTOR 2
Q106 UN4111 TRANSISTOR 1
Q110 2SC3311AR TRANSISTOR 1
Q301,02 2SC3311ATA TRANSISTOR 2
Q303 UN4115 TRANSISTOR 1
Q401 2SD2137PQTA TRAMSISTOR 1
Q402 2SB1417PQTA TRANSISTOR 1
Q403 2SC3940AQSTA TRANSISTOR 1
Q405 DTB123YSTP TRANSISTOR 1
Q406 DTC114ESTP TRANSISTOR 1
Q407 2SC3311ATA TRANSISTOR 1
Q541,42 2SC3311ATA TRANSISTOR 2
Q543 DTC143XSTP TRANSISTOR 1
Q701 UN5214TX TRANSISTOR 1
Q702 2SD1819ATX TRANSISTOR 1
R102 ERDS2FJ472 1/4W 4.7K 1
R103 ERDS2FJ101 1/4W 100 1
R104 ERDS2FJ103 1/4W 10K 1
R105 ERDS2FJ471 1/4W 470 1
R106 ERDS2FJ474 1/4W 470K 1
R107 ERDS2FJ331 1/4W 330 1
R108 ERDS2FJ474 1/4W 470K 1
R109 ERDS2FJ331 1/4W 330 1
19
