Technics ST-HD501

Ref. No. Part No. Part Name & Description
PCS
Remarks
1 RHD30073-K SCREW 4
2 RKM0398-S CABINET 1
3 XTB3+8JFZ SCREW 1
4 REZ1120 FLAT CABLE(14P) 2
5 RKA0076-N2 FOOT 4
5-1 RKA0083-K CUSHION 4
6 XTB3+6G SCREW 4
7 RMN0195 FL HOLD PIECE 2
8 RGK1138-N SIDE ORNAMENT(L) 1
9 RGK1139-N SIDE ORNAMENT(R) 1
10 RGU1394B-S BUTTON 1
11 XTBS26+8J SCREW 9
12 XTBS3+8JFZ1 SCREW 9
13 XTB3+12JFZ SCREW 4
14 RFKGTHD501EN FRONT PANEL ASS’Y 1
15 RGK0817-1M SIDE PANEL (L) 1
16 RGK0818-1M SIDE PANEL (R) 1
24
