Ground the soldering iron.
Put a conductive mat on the work table.
Do not touch the legs of IC or LSI with the fingers directly.
● Voltage and signal line
●
: Positive voltage line
●
: Negative voltage line
●
: Phono signal line
●
: Tape rec signal line
•@
