32 VGARLY O VGCA mode relay control signal output
33|
36
NC - Not used, open
37 SELPH - Not used, open
38 BATLVL2 - Battery voltage detection (2) signal input (Not used, open)
39 NC - Not used, open
40 RSWAD I Power switch (S805) detect signal input
41 KEYAD I Tape monitor and VGCA switch input
42 BATLVL1 - Battery voltage detection (1) signal input (Not used, open)
•@
